Lumiax High-end solar regulator RS485 LCD display bluetooth 40A 12V 24V Solar Charge Controller mppt
Lumiax High-end solar regulator RS485 LCD display bluetooth 40A 12V 24V Solar Charge Controller mppt
Regular price
$332.07 AUD
Regular price
$0.00 AUD
Sale price
$332.07 AUD
Unit price
per
Couldn't load pickup availability
Products Description
|
1.Supports customization and wholesale
|
|
2.Factory-type enterprise, research and development production. Strictly control the quality and provide convenience after sale.
|
|
3.Provide project customization, professional and technical personnel to provide one-stop service.
|
|
4.Innovative technology, preferred quality suppliers. Longer life and more productive than their peers.
|
Product Paramenters
|
ltem
|
MT4010
|
|
Max Charging Current
|
40A
|
|
System Voltage
|
12V/24V automatical recognization
|
|
MPPT Charging Voltage
|
before boost or equalization charging stage
|
|
Boost Voltage
|
14.0~14.8V/28.0~29.6V @25℃ (default14.5/29V)
|
|
Equalization Voltage
|
14.0~15.0V/28.0~30.0V @25℃ (default14.8/29.6V)
|
|
Float Voltage
|
13.0~14.5V/26.0~29.0V @25℃(default13.7/27.4V)
|
|
Low voltage disconnect
|
10.8~11.8V/21.6~23.6V,SOC1-5(default 11.2/22.4NV)
|
|
Low voltage reconnect
|
11.4~12.8V/22.8~25.6V (default: 12.0/24.0V)
|
|
Overcharge Protect
|
15.8/31.3V
|
|
Charging target voltage
|
10.0~32.0V(Lthium, default:14.4V)
|
|
Charging recovery voltage
|
9.2~31.8V(Lthium default: 14.0V)
|
|
Low voltage disconnect
|
9.0~30.0V(Lthium default: 10.6V)
|
|
Low voltage reconnect
|
9.6~31.0V(Lthium default: 12.0V)
|
|
Battery lype
|
Gel,AGM,Liquid,Lithium (default Gel)
|
|
Max volt on Bat. Terminal
|
35V
|
|
Max input power
|
520/1040W
|
|
Day/Night delay time
|
0~30min (default 0min)
|
|
MPPT tracking range
|
(Battery Voltage + 1.0V)--Voc*0.9
|
|
Output Current
|
30A
|
|
Load mode
|
Always on,Street lamp,User-defind Mode
|
|
Max tracking efficiency
|
>99.9%
|
|
Max charge conversion
|
98%
|
|
Dimensions(mm)
|
189*255*69mm
|
|
Weight
|
2KG
|
|
Communication
|
RS485(RJ11 interface)
|
|
Optional
|
Cyber-BT(lnternal/External)
|
|
Grounding
|
Common Negative
|
|
Power terminals
|
6AWG(16mm2)
|
|
Ambient temperature
|
-20 - +55℃
|
|
Storage temperature
|
-25~ +80℃
|
|
Ambient humidity
|
0~ 100%RH
|
|
Protection degree
|
IP32
|
|
Max Atitude
|
4000m
|
